Twin Wall Greenhouse ISO/CE by Jianda Greenhouse
Product details of the twin wall greenhouse
Quick Overview
We keep a close eye on the entire manufacturing process of Jianda Greenhouse twin wall greenhouse. Our company has passed the ISO9001quality system certification, providing a more reliable guarantee for the quality of the product. JIANDA's twin wall greenhouse is widely applicable in the industry. WEIFANG JIANDA GREENHOUSE MATERIAL CO.,LTD is well-funded, has advanced equipment and a group of highly skilled professionals.
Product Description
The twin wall greenhouse of JIANDA has been improved greatly in the following aspects.
Product Features
Generally, solar panel greenhouses are covered with 8mm solar panels. Because the solar panels are hollow materials, the top and sides of the greenhouse are covered with solar panels. The greenhouse has good sealing and good thermal insulation effect. However, compared with the glass greenhouse of the Venlo greenhouse, the sunlight polycarbonate Panel greenhouses have poor aesthetics.
Product Details
Intelligent commercial polycarbonate greenhouse greenhouse skeleton refers to intelligent greenhouse steel materials, including greenhouse greenhouse embedded parts, columns, truss beams, herringbone beams, perimeter beams outside the sunshade skeleton, transmission and so on.
The standard configuration of the sun plate greenhouse skeleton before talking about the details of the intelligent greenhouse skeleton materials:
Column 120*120*3.0 hot dip galvanized square tube
Deputy column 60*120*3.0 hot dip galvanized square tube
End column top cross pull 50*50*2.0 hot-dip galvanized square pipe
Transverse truss top and bottom chord 50*50*2.0 welded frame
Joist support 30*30 angle steel welded frame
Roof girder 30*50*2.0 hot-dip galvanized square tube
Roof purlin 30×50×2.0 hot dip galvanized square tube
Wall purlin 50×50×2.0 hot-dip galvanized square pipe
Outer sun-shading column 50×50×2.0 Hot-dip galvanized square pipe
External sunshade beam 50×50×2.0 hot-dip galvanized square pipe
External sunshade beam 30×50×2.0 hot-dip galvanized square pipe
Drainage gutter T=2.0 Aluminum zinc plated
Motor drive rod Diameter 32×2.0 Hot-dip galvanized round tube.
Product application
POLYCARBONATE GREENHOUSE IN MODERN AGRICULTURE
Intelligent commericial polycarbonate greenhouse greenhouse is also known as intelligent greenhouse or intelligent greenhouse, is now on the market in modern agriculture is more widely used in a kind of greenhouse. This structure of the greenhouse is generally a steeple shape, covered with hollow glass or hollow pc sunshine board, supporting the internal sunshade, external sunshade, fan water curtain cooling system, the span is generally 9.6 meters -12 meters, the opening is generally 4-8 meters.
Intelligent glass greenhouse greenhouse or intelligent sun panel greenhouse need to pay attention to the general length and width do not exceed 100 meters, because more than 100 meters in the summer when the greenhouse cooling function has declined, of course, we can also use the air and other cooling facilities such as cooling facilities to assist in cooling, then the resource energy consumption will increase.
Winter intelligent greenhouse greenhouse in the use of the general use of auxiliary heating system. We generally intelligent greenhouse in the construction of the supporting thermal insulation system, including the top of the internal thermal insulation system and the surrounding internal thermal insulation system, which can effectively make the intelligent greenhouse greenhouse in the winter to enhance the temperature.
Intelligent greenhouse greenhouse is widely used, planting, sightseeing and so on.
Company Introduction
WEIFANG JIANDA GREENHOUSE MATERIAL CO.,LTD always provides customers with reliable twin wall greenhouse products. In the manufacturing market of twin wall greenhouse, Jianda Greenhouse uses the most advanced technology. Market philosophy of Jianda Greenhouse: Win the market with quality, enhance brand with reputation. Get an offer!
We sincerely welcome customers with needs to contact us and cooperate with us!
